Polyethylene I Beam Flange Guard 7-1/2 In. x 36 In.

The Polyethylene I Beam Flange Guard is engineered to provide reliable impact protection for exposed I-beams, especially in areas where traditional column protectors cannot be installed due to obstructions. Ideal for warehouses and industrial facilities, this flange guard enhances workplace safety by shielding beam edges from contact with scissor lifts, elevated forklifts, and other equipment.

Molded from durable polyethylene, each unit is designed for quick and secure installation without the need for straps or fasteners. Use a single unit or stack multiple guards vertically for increased coverage and impact resistance.

Key Features & Benefits

• Obstacle-Friendly Installation – Easily fits beams obstructed by walls or adjacent structures.
• Stackable Design – Allows for vertical layering to protect against higher-reaching equipment.
• Tool-Free Setup – Special groove design enables secure installation with no fasteners required.
• Durable Polyethylene Construction – Provides long-lasting protection and resists cracking, corrosion, and weathering.
• Modular Coverage – Four units fully cover an I-beam for 360° protection (sold individually).

Additional Information:

This flange guard is ideal for areas with limited access where wrap-around protectors are impractical. Units are sold individually and can be combined as needed to meet specific protection height requirements. Suitable for indoor and outdoor use.

Technical Specifications:

• Total Ship Wt.(lbs.): 8
• Size: 8.5"W x 7.5"L x 36"H
• Application: I-Beam Protector
• Impact Resistance: Not Rated
• Mounting Method: Molded Groove-Slide in Place

• Package Contents: (1) I-Beam Protector
• Reflective: No
• Stackable: Yes

• Mounting Hardware Included: Not Required
• Color / Finish: Yellow
• Material: HDPE Polyethylene

• Width (in.): 8.5
• Height (in.): 36
• Depth (in.): 7.5
• UPC: 691215101356
• GTIN: 00691215101356
• Manufacturer Warranty: 1 year

Made in the USA
