Column Sentry FIT Small – Adjustable 16" OD Column Protector for 4"–8" Columns

The Column Sentry FIT Small is an adjustable four-sided column protector designed for square, round, and H-shaped columns measuring from 4" × 4" up to 8" × 8".

With a compact 16" outside diameter and 42" height, it is well suited for parking structures, mezzanines, warehouse columns, conveyors, interior building columns, and other locations where available space around the column is limited.

The interlocking four-sided design slides together around the column and adjusts to the required size. Once positioned, the included straps secure the protector in place without permanently attaching it to the column.

Features & Benefits

  • Adjustable Fit: Designed to fit square, round, or H-shaped columns from 4" × 4" through 8" × 8".
  • Four-Sided Protection: Interlocking design surrounds the column on all four sides for consistent coverage.
  • Compact 16" Outside Diameter: Suitable for mezzanines, conveyors, parking structures, and other areas where space is limited.
  • 42" Height: Provides a substantial protective zone around the lower portion of the column.
  • Patented Air-Vent Design: Allows air to escape during impact so the protector can flex without separating at the sides.
  • Impact-Absorbing Construction: Molded polymer construction is designed to flex and recover from repeated incidental contact.
  • HDPE / EVA Construction: Molded from a blend of high-density polyethylene and ethylene vinyl acetate.
  • Highly Visible Federal Yellow: Bright color increases the visibility of columns in vehicle and pedestrian areas.
  • Weatherproof Construction: Suitable for indoor and outdoor applications.
  • Chemical Resistant: Designed for demanding commercial and industrial environments.
  • UV-Stabilized: Formulated for exterior exposure.
  • Easy Installation: Installs around the existing column without drilling into the column.
  • Installation Straps Included: Straps secure the assembled protector around the column.
  • Stackable Design: Multiple units can be stacked where additional vertical coverage is required.
  • Made in the USA: Proudly manufactured in the United States.

Technical Specifications

Product Type Adjustable Column Protector
Model / SKU CS-FIT-S-Y
Outside Diameter 16"
Height 42"
Column Size Range 4" × 4" to 8" × 8"
Metric Column Size Range Approximately 100 × 100 mm to 200 × 200 mm
Compatible Column Shapes Square, Round & H-Shaped Columns
Construction Interlocking 4-Sided Design
Material Molded HDPE / EVA Blend
Color Federal Yellow
Environmental Properties Weatherproof, Chemical Resistant & UV-Stabilized
Installation Included Securing Straps
Warranty 30-Day Limited Warranty Against Manufacturing Defects

Adjustable Four-Sided Design

Unlike a fixed-size two-piece column protector, the Column Sentry FIT Small uses an interlocking four-sided configuration. Each side slides relative to the adjoining section so the protector can be adjusted around columns within the specified size range.

This design provides coverage around all four sides of the column while maintaining a consistent protective zone as the unit is adjusted.

Patented Air-Vent System

An integrated air-vent system allows air inside the protector to escape as the unit flexes during contact. This helps the sections absorb movement without forcing the sides apart and allows the molded material to recover after minor impacts.

Compact Protection for Smaller Columns

The 16" outside diameter makes the FIT Small especially useful where a larger column protector could interfere with surrounding traffic or equipment.

Typical installations include mezzanines, conveyors, parking-garage columns, interior structural columns, warehouse areas, and other locations with limited surrounding clearance.

High-Visibility Federal Yellow

The bright Federal Yellow finish increases the visibility of the column in parking, warehouse, industrial, and pedestrian environments.

In addition to providing cushioning around the underlying structure, the highly visible exterior helps make fixed columns easier to identify for drivers and pedestrians.

Installation

The four interlocking sections assemble around the existing column and are secured using the included straps. No drilling into the column is required.

View Installation Instructions

Common Applications

  • Parking structure columns
  • Parking garage support columns
  • Warehouse columns
  • Interior building columns
  • Mezzanine supports
  • Conveyor support columns
  • Manufacturing facilities
  • Distribution centers
  • Commercial buildings
  • Areas with vehicle or material-handling traffic

Important Application Note

The Column Sentry FIT Small is designed to provide impact cushioning and increased visibility around structural columns. Its effectiveness depends on the type, speed, direction, and energy of an impact as well as the installation and underlying structure.

No certified crash rating or specific vehicle-impact speed classification has been provided with the supplied product information. It should not be represented as a crash-rated barrier.

Made in the USA

The Column Sentry FIT Small is proudly manufactured in the United States.

Made in the USA

Product Videos

Technical Resources

View Installation Instructions

View Mechanical Drawings
